• Speed: up to 60 straps/min
• Tension: digitally adjustable up to 176 lbf
• Strap widths: 1/4", 3/8", 1/2"
• Strap type: polypropylene
• Standard arch: 690 mm W × 400 mm H (approx. 27" × 16")
• Maximum package size: 620 mm W × 380 mm H (approx. 24-1/2" × 15")
• Minimum package size: 80 mm W × 30 mm H (approx. 3-1/8" × 1-1/8")
• Machine width: 1052 mm with handles (approx. 41-3/8")
• Machine height: 1445 mm (approx. 56-7/8")
• Machine depth: 609 mm (24")
• Table height: 936 mm (36-7/8")
• Machine weight: approximately 355 lb (161 kg)
• Power: 100/120/220/230/240V, single phase, 50/60Hz
• Power consumption: 0.74 KVA
• Integrated hands-free foot arm switch
• Internal strap reel
• Automatic re-feed and loop ejection
• Self-lubricating design

Resources

• Download SQ-800IR3 Specification Sheet
